Support Vector Machine (SVM) is a supervised learning algorithm that can be used for both classification and regression tasks. SVM is particularly effective in high-dimensional spaces and is versatile thanks to the use of different kernel functions that allow finding optimal separating hyperplanes in transformed feature spaces.
The SVM algorithm was developed by Vladimir Vapnik and colleagues at AT&T Bell Laboratories during the 1990s. The fundamental idea emerged from statistical learning theory and structural risk minimization. Since its introduction, SVM has been widely adopted in various applications, from text recognition to bioinformatics, establishing itself as one of the most robust and versatile algorithms in machine learning.
import numpy as np
from sklearn.svm import SVC
from sklearn.preprocessing import StandardScaler
class SVM:
def __init__(self, kernel='rbf', C=1.0):
self.scaler = StandardScaler()
self.svm = SVC(kernel=kernel, C=C)
def fit(self, X, y):
# Normalize the data
X_scaled = self.scaler.fit_transform(X)
# Train the model
self.svm.fit(X_scaled, y)
def predict(self, X):
# Normalize input data
X_scaled = self.scaler.transform(X)
# Make prediction
return self.svm.predict(X_scaled)
def get_support_vectors(self):
# Get support vectors
return self.scaler.inverse_transform(
self.svm.support_vectors_
)
# Example usage
if __name__ == "__main__":
# Generate sample data
np.random.seed(0)
X = np.random.randn(100, 2)
y = (X[:, 0] + X[:, 1] > 0).astype(int)
# Create and train the model
svm = SVM(kernel='rbf', C=1.0)
svm.fit(X, y)
# Make predictions
X_test = np.random.randn(10, 2)
predictions = svm.predict(X_test)
print("Predictions:", predictions)
#include
#include
#include
#include
class SVM {
private:
double C;
std::string kernel_type;
std::vector weights;
double bias;
std::vector> support_vectors;
// RBF (Gaussian) kernel function
double rbf_kernel(const std::vector& x1,
const std::vector& x2,
double gamma = 0.1) {
double squared_norm = 0.0;
for(size_t i = 0; i < x1.size(); ++i) {
double diff = x1[i] - x2[i];
squared_norm += diff * diff;
}
return std::exp(-gamma * squared_norm);
}
// Linear kernel function
double linear_kernel(const std::vector& x1,
const std::vector& x2) {
double sum = 0.0;
for(size_t i = 0; i < x1.size(); ++i) {
sum += x1[i] * x2[i];
}
return sum;
}
// Calculate kernel based on selected type
double kernel_function(const std::vector& x1,
const std::vector& x2) {
if(kernel_type == "rbf") {
return rbf_kernel(x1, x2);
}
return linear_kernel(x1, x2);
}
public:
SVM(const std::string& kernel = "rbf", double c = 1.0)
: C(c), kernel_type(kernel), bias(0.0) {}
void fit(const std::vector>& X,
const std::vector& y,
int max_iterations = 100) {
const int n = X.size();
weights.resize(n, 0.0);
bool changed;
int iteration = 0;
do {
changed = false;
for(int i = 0; i < n; ++i) {
double Ei = predict(X[i]) - y[i];
if((y[i] * Ei < -0.01 && weights[i] < C) ||
(y[i] * Ei > 0.01 && weights[i] > 0)) {
// Randomly select second point
int j;
do {
j = rand() % n;
} while(j == i);
double Ej = predict(X[j]) - y[j];
// Save old values
double old_wi = weights[i];
double old_wj = weights[j];
// Calculate bounds
double L = std::max(0.0, old_wj + old_wi - C);
double H = std::min(C, old_wj + old_wi);
if(L == H) continue;
// Calculate eta
double eta = 2 * kernel_function(X[i], X[j]) -
kernel_function(X[i], X[i]) -
kernel_function(X[j], X[j]);
if(eta >= 0) continue;
// Update weights
weights[j] = old_wj - y[j] * (Ei - Ej) / eta;
weights[j] = std::min(H, std::max(L, weights[j]));
if(std::abs(weights[j] - old_wj) < 1e-5) continue;
weights[i] = old_wi + y[i] * y[j] *
(old_wj - weights[j]);
// Update bias
double b1 = bias - Ei - y[i] * (weights[i] - old_wi) *
kernel_function(X[i], X[i]) -
y[j] * (weights[j] - old_wj) *
kernel_function(X[i], X[j]);
double b2 = bias - Ej - y[i] * (weights[i] - old_wi) *
kernel_function(X[i], X[j]) -
y[j] * (weights[j] - old_wj) *
kernel_function(X[j], X[j]);
bias = (b1 + b2) / 2;
changed = true;
}
}
++iteration;
} while(changed && iteration < max_iterations);
// Save support vectors
for(size_t i = 0; i < weights.size(); ++i) {
if(weights[i] > 0) {
support_vectors.push_back(X[i]);
}
}
}
double predict(const std::vector& x) {
return bias;
double sum = 0.0;
for(size_t i = 0; i < support_vectors.size(); ++i) {
sum += weights[i] * kernel_function(x, support_vectors[i]);
}
return sum + bias;
}
};
// Example usage
int main() {
// Generate sample data
std::vector> X = {
{1, 2}, {2, 3}, {3, 1}, {-1, -2}, {-2, -1}, {-3, -2}
};
std::vector y = {1, 1, 1, -1, -1, -1};
// Create and train model
SVM svm("rbf", 1.0);
svm.fit(X, y);
// Make predictions
std::vector test_point = {2, 2};
double prediction = svm.predict(test_point);
std::cout << "Prediction: " << (prediction > 0 ? 1 : -1) << std::endl;
return 0;
}
using System;
using System.Collections.Generic;
using System.Linq;
public class SVM
{
private double C;
private string kernelType;
private double[] weights;
private double bias;
private List supportVectors;
public SVM(string kernel = "rbf", double c = 1.0)
{
C = c;
kernelType = kernel;
bias = 0.0;
supportVectors = new List();
}
// RBF (Gaussian) kernel function
private double RbfKernel(double[] x1, double[] x2, double gamma = 0.1)
{
double squaredNorm = x1.Zip(x2, (a, b) => a - b)
.Select(diff => diff * diff)
.Sum();
return Math.Exp(-gamma * squaredNorm);
}
// Linear kernel function
private double LinearKernel(double[] x1, double[] x2)
{
return x1.Zip(x2, (a, b) => a * b).Sum();
}
// Calculate kernel based on selected type
private double KernelFunction(double[] x1, double[] x2)
{
return kernelType == "rbf" ? RbfKernel(x1, x2) : LinearKernel(x1, x2);
}
public void Fit(double[][] X, int[] y, int maxIterations = 100)
{
int n = X.Length;
weights = new double[n];
bool changed;
int iteration = 0;
do
{
changed = false;
for(int i = 0; i < n; i++)
{
double Ei = Predict(X[i]) - y[i];
if((y[i] * Ei < -0.01 && weights[i] < C) ||
(y[i] * Ei > 0.01 && weights[i] > 0))
{
// Randomly select second point
Random rand = new Random();
int j;
do
{
j = rand.Next(n);
} while(j == i);
double Ej = Predict(X[j]) - y[j];
// Save old values
double oldWi = weights[i];
double oldWj = weights[j];
// Calculate bounds
double L = Math.Max(0, oldWj + oldWi - C);
double H = Math.Min(C, oldWj + oldWi);
if(L == H) continue;
// Calculate eta
double eta = 2 * KernelFunction(X[i], X[j]) -
KernelFunction(X[i], X[i]) -
KernelFunction(X[j], X[j]);
if(eta >= 0) continue;
// Update weights
weights[j] = oldWj - y[j] * (Ei - Ej) / eta;
weights[j] = Math.Min(H, Math.Max(L, weights[j]));
if(Math.Abs(weights[j] - oldWj) < 1e-5) continue;
weights[i] = oldWi + y[i] * y[j] *
(oldWj - weights[j]);
// Update bias
double b1 = bias - Ei - y[i] * (weights[i] - oldWi) *
KernelFunction(X[i], X[i]) -
y[j] * (weights[j] - oldWj) *
KernelFunction(X[i], X[j]);
double b2 = bias - Ej - y[i] * (weights[i] - oldWi) *
KernelFunction(X[i], X[j]) -
y[j] * (weights[j] - oldWj) *
KernelFunction(X[j], X[j]);
bias = (b1 + b2) / 2;
changed = true;
}
}
iteration++;
} while(changed && iteration < maxIterations);
// Save support vectors
for(int i = 0; i < weights.Length; i++)
{
if(weights[i] > 0)
{
supportVectors.Add(X[i]);
}
}
}
public double Predict(double[] x)
{
return supportVectors.Select((sv, i) =>
weights[i] * KernelFunction(x, sv)).Sum() + bias;
}
// Example usage
public static void Main()
{
// Generate sample data
double[][] X = new double[][]
{
new double[] {1, 2},
new double[] {2, 3},
new double[] {3, 1},
new double[] {-1, -2},
new double[] {-2, -1},
new double[] {-3, -2}
};
int[] y = new int[] {1, 1, 1, -1, -1, -1};
// Create and train model
SVM svm = new SVM("rbf", 1.0);
svm.Fit(X, y);
// Make predictions
double[] testPoint = new double[] {2, 2};
double prediction = svm.Predict(testPoint);
Console.WriteLine($"Prediction: {(prediction > 0 ? 1 : -1)}");
}
}
